Vivax-Metrotech vCam-6 HD Video Pipe Inspection System

The vCam-6 HD professional pipe inspection camera system from Vivax-Metrotech is our best-equipped camera system. It offers full 1024x768 high-definition resolution video via its 1.3" (D34-HD) or its 1.8" (D46-HD) high definition 1080p camera heads. Camera lighting up to 44.02 Lumens (D46-HD). The vCam-6 HD screen is an industry-leading 9.7" Daylight viewable display.

A choice of two professional-grade reels, i.e., type-CP reel (200/300/400ft), is the larger variant with a stainless-steel frame construction. The MX compact reel (100/150ft) is a stainless steel frame with a high-strength carbon fiber drum. Both materials eliminate rust and corrosion, commonly found to occur on older lower-cost painted steel frame designs.

Every vCam-6 HD includes built-in 1-TB (Terabyte) HD for video storage and an internal Li-Ion battery (4-6 hr.). However, it can also run on any 120VAC main outlet or 12DC auto outlet. Other features include "Locatable" push-rod, built-in sonde (512Hz/640Hz/33kHz), and Wi-fi (150ft range) for smartphone/tablet app use.

There are hidden images / Tidy mode active.

Camera System Features - vCam-6

Slide show provided by Vivax-Metrotech.

Hover on slide to stop and move curser off slide to re-start.

Scroll

vCam-6-HD Standard Features

9.7" (1024 x 768) HD Daylight viewable LCD

1080p self-leveling camera heads

Wi-fi with FREE Vivax-Metrotech smartphone/tablet app (iOS & Android)

One-touch recording and image capture

1 Terabyte (1TB) internal hard drive for onboard video storage

Record directly to built-in 1TB-HD or USB drive

AC/DC operation with Li-Ion rechargeable battery as standard

Stainless-steel tubular frame reel with stainless hardware

4-hour battery life (6-hour with sonde off)

12mm diameter (standard rod) & 13mm diameter (Optional RED rod)

200ft. / 300ft. / 400ft. (Available rod lengths)

Built-in camera sonde - 512Hz / 640Hz / 33kHz

Traceable/Locatable Rod (using an external pipe locator & transmitter)

USB Data port for LACP software interface

Internal microphone and On-Screen digital counter (with reset button)

Camera test port (for serviceability ease)

Full QWERTY keyboard

Self-leveling camera head sizes: 1.3" (D34-HD) & 1.8" (D46-HD)

Camera Construction: Stainless-steel housing & Sapphire lens

Field serviceable spring with coiled cable and lanyards

Camera Resolution: 1080p

Field of view: 96°

Camera Environmental: 11 Bar

Camera Lighting: 12.97 Lumens (D34-HD) & 44.01 Lumens (D46-HD)

D34-HD
D46-HD

D34-HD
The D34-HD offers unique 1.3" size diameter with x 2.9" length providing industry leading1080p HD performance.

D34-HD & D46-HD Camera Features

Self-leveling camera head sizes: 1.3" (D34-HD) & 1.8" (D46-HD)

Camera Construction: Stainless-steel housing & Sapphire lens

Field serviceable spring with coiled cable and lanyards

Camera Resolution: 1080p

Field of view: 96°

Camera Environmental: 11 Bar

Camera Lighting: 12.97 Lumens (D34-HD) & 44.01 Lumens (D46-HD)

Type CP - Standard
The standard reel is wide enough to roll without tipping but slim enough to go through doorways and gates. - all stainless steel construction and includes friction and locking brakes. The control module can mount on this reel for easy viewing.
200ft, 300ft or 400ft 12mm diameter locatable pushrod cable. Optional 13mm diameter (RED) rod available.

Suitable Camera options:

D46-HD (1.8") self-leveling
D34-HD (1.3") self-leveling

12mm (standard)
13mm (heavy-duty)

Ball Skids
Type B Skids

D34-HD Skids
2.111.05.00002	Guide Skid, 2.25"
2.111.05.00003	Guide Skid, 3"
2.111.05.00004	Guide Skid, 4"

D46-HD Skids
2.109.10.00006	Guide Skid, 3"
2.109.10.00003	Guide Skid, 4"
2.109.10.00004	Guide Skid, 5"

vCam-6 LiveView App

The vCam-6 LiveView mobile app from Vivax-Metrotech provides users a live video stream from the vCam-6 pipe inspection camera system onto their iOS iPhone or iPad.

This video stream allows users to record video and capture JPEG pictures on their iOS device. Users can easily share the files using your built-in iOS file sharing features.

Rename files
Record video and capture JPEG pictures
Edit files in the Apple iMovie video editing app
Share via iOS file sharing features (email, text message, or 3rd party such as DropBox or OneDrive, etc.)

The vLoc3-Cam sonde locator from Vivax-Metrotech is built on a new Triaxial 3D antenna architecture providing the best-in-industry sonde locating experience. The vLoc3-Cam makes finding and locating sondes and camera heads quick and easy every time. Approach the sonde from any direction, and the bright color LCD will guide you to the exact location of the camera head with depth.

The vLoc3-Cam includes all the industry-standard sonde frequencies and a line trace frequency for locating the entire length of the camera pushrod. In addition, an optional transmitter is available for this application. The vLoc3-Cam also includes passive Power and Radio modes for traditional utility sweeping.

Graphical locate layout (best sonde mode on the market)
Pushrod and Line trace: *83kHz only.
Active frequencies (sonde): 512Hz / 640Hz / 8.19kHz / 9.82kHz / 33kHz / 83kHz
Passive: Power 60Hz / Radio

*requires an optional portable transmitter

The vScan receiver is both a line & sonde locator. The vScan receivers antenna orientation makes it ideal for sonde locating. It includes the two most popular sonde frequencies used by pushrod camera manufacturers - 512Hz & 33kHz. A passive power 60Hz and Radio mode for locating passive signals radiating from adjacent pipes and cables allows users to sweep for known and unknown utilities.

*Optional: Transmitter for pipe locating
Optional: Metal detection mode
Active frequencies (sonde): 512Hz / 640Hz / 33kHz
*Active (line): 33kHz / 131kHz
Passive: Power 60Hz / Radio

*requires an optional portable transmitter

The VM-540 receiver locates pushrod camera heads and sondes. It includes the two most popular sonde frequencies used by pushrod camera manufacturers - 512Hz & 33kHz. A passive power 60Hz mode for locating signals radiating from adjacent pipes and cables provides users an ability to sweep for both known and unknown utilities.

Visual and audio response
Lightweight and compact design
Cost Effective (our most affordable option)
Active frequencies (sonde): 512Hz / 640Hz / 33kHz
Passive: Power 60Hz

Basic Operation - vCam-6

Slide show provided by Vivax-Metrotech.

Hover on the slide to stop and move the cursor off the slide to re-start.

Scroll

2023 Tracer Electronics LLC

Vivax-Metrotech vCam-6 HD Video Pipe Inspection System

Type B Skid (fits D34-HD & D46-HD)
2.104.20.00001	Type-B Adjustable Skid
1.104.20.00001	Type-B Adjustable Skid with Light Kit
2.104.05.00003	Light Kit - Type-B
